PRS Neck Profiles Explained: Pattern, Pattern Thin, Pattern Regular, and Pattern Vintage

Here's the short version, because it's the part most people get backwards: on a modern core PRS, the four main neck carves are almost the same width. What actually changes from one to the next is depth — how much wood is filling your palm front to back. From slimmest to fullest, the order is Pattern Thin, then Pattern Regular, then Pattern, then Pattern Vintage. That's the whole map. Everything else is detail.

I've had a lot of these across the bench — SE, S2, CE, and core — and the neck is the single spec people most often misread when they're buying a PRS used. So let's clear it up in plain language, with the actual numbers, and I'll tell you honestly how much of it you'll feel.

First, ignore the old names (mostly)

PRS re-tooled and renamed its neck shapes in the early 2010s, and the new names are the ones you'll see on almost any guitar built since. The lineage is simple:

Pattern is the updated version of the old Wide Fat. Pattern Thin is the updated Wide Thin. Pattern Regular is the updated Regular (sometimes called Standard). PRS says the Pattern shape itself is based on Paul's pre-factory necks from the late '70s and early '80s — the ones on guitars he built for players like Santana and Howard Leese.

The word that trips everyone up is "Wide." On a used listing you'll read "Wide Thin" and picture a wide neck. It isn't. "Wide" refers to the nut width heritage, and in practice almost every core PRS carve measures right around 1 11/16" (about 42.9 mm) at the nut — roughly the same nut width as a typical Gibson. So a "Wide Thin" is a normal-width neck that happens to be shallow. Read the second word, not the first.

The four core carves, and who each one suits

Pattern Thin

The thinnest carve PRS puts on an American-made guitar. Published depth is roughly 21.0 mm at the first fret and 22.6 mm at the twelfth. This is the modern-feeling one: fast, shallow, easy on players coming from a thin Ibanez or a slim-taper Strat. It's the default on Custom 24–style models and a lot of S2 and SE guitars. If you like a low, get-out-of-the-way neck, start here.

Pattern Regular

A hair slimmer at the nut (about 1 21/32") and shaped rounder than you'd expect — roughly 21.4 mm at the first fret, 23.4 mm at the twelfth. It splits the difference: not a baseball bat, but with enough shoulder to fill your hand. Players who find truly thin necks cause thumb cramping over a long set tend to land here and relax.

Pattern

The full one — the updated Wide Fat. Same nut width as Pattern Thin but noticeably deeper, about 22.2 mm at the first fret and 24.2 mm at the twelfth. This is the carve for people who like to feel the neck. It's common on Custom 22–style models. If you've ever played a chunky late-'50s-style Gibson and thought "yes, that," Pattern will feel like home.

Pattern Vintage

Same width as Pattern, but a touch deeper front to back and — this is the interesting part — asymmetrical. PRS shaves a little off the bass side down near the nut and a little off the treble side up past the twelfth, so it fills the hand without feeling like a log. Depth runs to about 25.0 mm by the twelfth fret, making it the fullest of the four. You'll see it on McCarty and 594 models, where the whole design is chasing a vintage feel.

There are also signature and specialty carves — the DGT (David Grissom), the JM, various artist necks — but if you understand the four above, you understand the system. The rest are variations on the same theme.

What about SE and S2 necks?

This is where used buyers get tangled, because the names shifted over the years. Today most S2 and a lot of SE guitars use the Pattern family names — frequently Pattern Thin or Pattern Regular. Older SE guitars, though, were spec'd as SE Wide Thin or SE Wide Fat. Worth knowing: PRS's own figures put the SE Wide Thin at about 20.6 mm at the first fret — actually the shallowest neck in the entire lineup down at the nut, thinner even than the American Pattern Thin. So if a slim neck is what you're after, an older Wide Thin SE is nothing to apologize for.

The practical rule: don't trust the model name to tell you the carve — check the spec for that specific year. PRS changed neck assignments across model runs, and a 2014 SE and a 2022 SE of the "same" model can carry different necks. When we list a used PRS, the neck profile is one of the first things we confirm and note.

Does the neck carve change the tone?

Honestly? Not in any way I'd stake my name on. People will tell you a fatter neck means more sustain and a "bigger" tone. There's a sliver of engineering logic there — more mass, more stiffness — but on a solidbody electric it's swamped by pickups, strings, setup, and your hands. I would never tell a customer to buy a neck they don't like the feel of because it might sound 2% warmer. It won't, in any way you'll notice through an amp.

Where the carve absolutely matters is comfort and fatigue, and that changes how you play, which is the tone that actually reaches the audience. A neck that fights your hand for three hours makes you play worse. A neck that disappears lets you concentrate on the music. That's the real payoff, and it's worth taking seriously.

So which PRS neck should you buy?

Don't overthink the names. Remember that the spread from the thinnest core carve to the fullest is only about 2 mm at the twelfth fret — real, but small. Most players are perfectly happy on Pattern Thin and never think about it again. If thin necks make your thumb cramp, or you're coming off a big vintage Gibson, look at Pattern or Pattern Vintage. If you want the middle path, Pattern Regular.

And if you can, play the actual guitar — or buy from someone who'll tell you the truth about the carve and the setup before it ships. That five minutes tells you more than any spec chart. You can see what's on the bench right now over in our guitars in stock, and every used PRS we list gets its neck profile confirmed rather than guessed.

FAQ

Is PRS Pattern Thin the same as the old Wide Thin?
Effectively yes — Pattern Thin is the re-tooled, current version of the old Wide Thin carve on American-made guitars. The Korean SE Wide Thin is a separate spec and is actually a touch shallower at the nut.

Which PRS neck is the thinnest?
Among US carves, Pattern Thin. Across the whole line, the SE Wide Thin measures the shallowest at the first fret, at roughly 20.6 mm.

What neck is on a PRS Custom 24 vs a Custom 22?
As a general rule Custom 24–style models run Pattern Thin and Custom 22–style models run the fuller Pattern — but this has varied by year, so confirm the spec on the specific guitar you're buying.

Does a thicker neck sustain longer or sound better?
Not in a way you'll hear on a solidbody electric. Choose the carve by feel and comfort; let the pickups and setup handle the tone.
